Will This Part Fit My Appliance?

Choose your brand from the list below to check your model compatibility.

Start typing your model number below to check compatibility.

Suitable For Models Of

Balay, Bauknecht, Blaupunkt, Bosch, Constructa, Cylinda, Gaggenau, Ikea, Junker, Koenic, Kuppersbusch, Lord, Neff, Pitsos, Profilo, Siemens, V zug, Viva, Zelmer Dishwashers

Description

What does the heat exchanger outlet valve do in a dishwasher?

The heat exchanger outlet valve transfers heat between the hot water used for cleaning and the incoming cold water supply. It’s at the bottom of the dishwasher tub and consists of a series of tubes or plates.

During operation, the heat exchanger uses the heat from the wastewater being drained to preheat the incoming cold water, which helps to reduce energy consumption by the dishwasher.

The preheated water then enters the wash cycle, ensuring that the dishwasher operates at the desired temperature for optimal cleaning and sanitization.

Why do you replace your heat exchanger outlet valve?

A malfunctioning valve might produce uneven washing results, leaving some dishes cold and others overheated.

Over time, the valve develops leaks, blockages, or malfunctioning mechanisms that prevent it from functioning properly. When the heat exchanger outlet valve fails, it leads to inadequate water circulation and inefficient heating within the dishwasher.

Would this heat exchanger outlet valve work in my oven?

This heat exchanger outlet valve is a genuine Bosch dishwasher replacement part. It also fits Balay, Blaupunkt, Constructa, Gaggenau, Ikea, Junker, Koenic, Kuppersbusch, Neff, Siemens, and Viva dishwashers.

Manufacturers Part Number:

  • 11033896

Alternative Part Numbers:

  1. 00631199
  2. 33896

Will this part fit your appliance?

Use our compatibility checker, Click here.

Finding your model number:

Struggling to find the model number on your Dishwasher? Click here.

Safety note:

Warning: Always unplug any appliance from the electricity supply before carrying out any work or testing on it.

Latest Product Review(s)

Read All Reviews
19 Customer Review(s)

Easy to find

This part was not available on most other sites but managed to source one from here very easily

By Melissa Dyer - Cheshunt
4th May 2023

Overall

Quality

Value

Ease of Fitting

Great product and service

I ordered this part after my dishwasher stopped working with an E19 error code, and several reviews had said this part could be faulty. The part was easy to order, in stock and arrived quickly. After reading reviews I was expecting the process to be fiddly and take a while to do but the dishwasher was drained, the old part removed and the new part fitted within 30 minutes. No fuss, no mess just one happy customer with a working dishwasher at a fraction of the cost of a new one.

By Serena - Hitchin
10th Feb 2023

Overall

Quality

Value

Ease of Fitting

Straightforward to fit with the help of internet video

Received notorious E19 code on my Neff dishwasher. Internet suggested it was replacing this part of the whole machine, so i thought i had little to lose. Part arrived quickly and the job was straightforward (the hardest bit was 'unfitting' the 'fitted' dishwasher to pull it out and access to part). Seems to work perfectly now.

By Rob Jones - Glasgow
24th Jan 2023

Overall

Quality

Value

Ease of Fitting

No engineer needed

Bosch said for an E19 error code you need an engineer visit. However, this was not difficult to fit and fixed the issue for me. The addition of a small heat shield made fitting the new part a bit of a pain and I didn’t get it quite right first time resulting in a small leak and E15 error code. But once I’d refitted this valve properly and dried up the cut off device the dishwasher has worked a treat since. Dishwasher was 5 years old before this failed so for £20 if I get another 5 years I’ll be very happy

By Chris Walder - Taunton
13th Dec 2022

Overall

Quality

Value

Ease of Fitting

Buy Original Part - with Heat Shield included

I recommend you buy this original part rather than an OEM part as the package comes with a heat protective foil to retrofit the dishwasher. I guess Bosch have finally realised that putting a heat shield between the valve and the heat exchanger to save the valve is a good idea! Other than that, watch the fitting videos and with a little patience the valve is easy to fit. Ransomes sales and delivery process was perfect so no complaints at all.

By Bob Billers - Crowthorne
21st Nov 2022

Overall

Quality

Value

Ease of Fitting

Great Product, quick delivery and easy to fit.

Another great part from Ransom Spares. Great price, quick delivery and excellent customer service. Recommended by our dishwasher engineer. Would use again!

By Nicola Beech - Reading
21st Nov 2022

Overall

Quality

Value

Ease of Fitting

NEFF DISHWASHER HEAT EXCHANGER OUTLET VALVE

The valve worked fine once I managed to fit it as its quite awkward to install. Jorden at Ransom was very helpful and I really appreciated his help.

By Ron Rawlinson - Liverpool
12th Oct 2022

Overall

Quality

Value

Ease of Fitting

Great Repair

Instructions good, worked first time. Ransom provides good advice and have used them before.

By paul Gosling - Bromley
6th Sep 2022

Overall

Quality

Value

Ease of Fitting

Direct replacement

Direct replacement & good value. Nothing more to say really.

By Andrew Orchard - Crewkerne
24th Aug 2022

Overall

Quality

Value

Ease of Fitting

Great all round

The part arrived on time, it was easy to fit and did the job perfectly. Probably saved me many ££'s as did the job myself rather than having to pay a call out charge.

By Penelope Jane Hunking - Woking
28th May 2022

Overall

Quality

Value

Ease of Fitting

Load More Reviews

Questions And Answers

Be the first to ask a question for this product.

Ask a new question
